Up - The High Speed Link is up and provides bandwidth available for services. When
HSL is up, the Linked NE information is available (presenting the sum of data rates of
the link) and displayed with Linked NE TID and HSL-<ID> (as numbered on remote
site).
Down - The High Speed Link is down and no bandwidth is provided for services.
Not Calibrated - Calibration was not performed. All provisioned (enabled) modems are
synchronized or trying to synchronize at minimal rate.
Calibrated to US and DS rates - Calibration was performed for all modems that were
enabled during last calibration. Calibration information includes information about
modems that successfully passed or failed qualification. All enabled but not qualified
(failed to qualify) modems are not trying to synchronize at all, even at minimal rate.
Calibrating,% (Retry <number>) - The link is down due to calibration in progress. If
new calibration was requested, it is suspended until on-going calibration is auto-
aborted (it takes a few minutes) and then starts automatically. The number of retries
is displayed.
Endless retries may indicate on wrong profile settings (e.g VDSL2 profile on very long
loop). Stop the calibration by clicking the Stop Calibration button. Ethernet service
capabilities of the HSL will be displayed as Available BW in Bandwidth parameters
Pending Calibration - Requested calibration is pending, waiting for enabled modems
to synchronize. For additional reasons, see the following table.
The link is down due to HSL currently in recovery process. System is attempting to
synchronize enabled modems. Service will be resumed automatically. This may take a
few minutes.
