Appendix E - Factory Setup Content
ML700 User Manual E-3
VLAN Tag type
0x8100
PPPoE tunnel forwarding
Disabled.
FRWDB learning
Enabled
FRWDB aging
Enabled, 300 sec
IGMP Snooping
Bridge Level ON, per VLAN OFF
VLANs
VLANs
Simultaneous support up to 256 VLANs, in range {1-4095}.
NOTE: VID=4093 is permanently reserved (for PPPoE feature), VID=4092
is permanently reserved
MGMT VLAN
VID= 100 is set for CPU, COLAN (untagged), and all HSL (tagged), even
not entered
Service VLAN
VID=101: ETH-1/S + HSL-1/T
VID=102: ETH-2/S + HSL-1/T
VID=103: ETH-3/S + HSL-1/T
VID=104: ETH-4/S + HSL-1/T
VID=105: ETH-5/S + HSL-1/T
Where S - Stacked, T- Tagged
Ethernet Bridge CoS
Scheduler type
2 SP (Strict Priority) – 6 WFQ (Weighted Fair Queue), 6 queues with
weights (configurable): H-8, MH-4, ML-2, L-2, LL-1, LLL-1
WFQ
CLASS weights un-configurable
Highest (HH) -8, High (MH)-4, Medium (L)-2, Low (LLL)-1
L2Prio-to-CLASS
classification
COS bits {0,1} – Low (LLL), COS bits {2,3} – Medium (L), COS bits {4,5}
– High (MH), COS bits {6,7} – Highest (HH).
L3Prio-to-CLASS
classification
TOS bits {0-15} – Low, TOS bits {16-31} – Medium, TOS bits {32-47} –
High, COS bits {48-63} - Highest.
L2Prio Translation
(HSL ingress applicable)
transparent (L2Prio is unchanged)
CLASS-to-L2Prio mapping
(HSL egress applicable)
HHH - 7, HH - 6, H - 5, MH - 4, ML - 3, L - 2, LL - 1, LLL - 0
Ethernet Port QoS
Classification
on ETH-x – “by L2PRIO”, on COLAN – HH (Enforced)
Ingress rate limiting
OFF on all allowed ports (allowed on ETH-x, HSL, COLAN)
Egress rate limiting
OFF on all allowed ports (allowed only on HSL)
Ingress Limit burst
Not allowed (per bridge configured)
Ethernet Services (BW limiting)
EVCs
not entered
CFM / MEF OAM
Y.1731 compliant
IGMP Snooping for
IGMPv1/v2
RFC4541 for RFC 1112/2236
STP
STP system-wide
Disabled. When enabled, protocol type is set to RSTP by default.
Port setting
ON in all ETH ports (ETH-x, COLAN and HSL).
