Appendix F - Alarms Troubleshooting

ML700 User Manual F-13

Condition

Type

Description

Recommended Troubleshooting Procedure

CFLT

Alarm was obsolete in R7.12.

Connectivity Failure problem is

detected and reported on MEP

(Maintenance End Point)

AID.Alarm indicates one of the

any possible defects (known in

SNMP as: rdi, errmac, rmepccm,

errccm, xconccm).

AID=MEP
