Appendix I - Recommended Actelis MiTOP Configuration Parameters
ML700 User Manual I-7
Parameter
Default Value
Menu Path
Set
Notes
Out PW Label
16
Optional
Defines outgoing PW label.
Needs to be changed if more
than a single MiTOP SFP exists
in the system.
In PW Label
16
Optional
Defines incoming PW label.
Enable
Reorder
Packets
Enable
Configuration >
Applications > Multiservice
over PSN > PW > PSN
Parameters
Optional
Enable packet reordering.
TOS
0
Optional
Define ToS value.
VLAN Tagging
Disable
Optional
Enable/Disable VLAN tagging.
Both options are valid, ETH-x
port on ML should be set
appropriately.
VLAN Priority
0
Optional
Defines VLAN priority value (if
VLAN tagging is enabled).
VLAN ID
1
Optional
Define VLAN ID (if VLAN
tagging is enabled).
Ingress Label
16
Optional
Define ingress MPLS tunnel
label (valid only for MPLS
network).
Egress Label
16
Optional
Define egress MPLS tunnel
label (valid only for MPLS
network).
EXP bit
0
Optional
Define EXP bits value (valid
only for MPLS network).
TTL
0
Optional
Defines Time-To-Leave value
(valid only for MPLS network).
Payload Size
256 bytes
Configuration >
Applications > Multiservice
over PSN > PW > Service
Parameters
Optional
Define TDM payload size, low
payload size would increase
HSL required BW.
Jitter Buffer
500 usec
Must
Define jitter buffer, set to
2000usec or higher.
E3, T3 port
number
1
X
Only valid value is 1.
