High Speed Link (HSL) Equipment and Port Configuration
5. To set a minimum bandwidth threshold, under which an alarm will be invoked and which
may be used in case of multi-mode calibration:
Checkmark LOWBW Threshold DS and LOWBW Threshold US and enter the low
BW threshold for this link within the displayed range. This does not initiate the BW
restoration procedure, it only generates an alarm.
6. Set Quarantine feature – when feature is enabled on HSL, its modem(s) may be
automatically removed (temporarily) from HSL (they remain synchronized but are not
used to send data traffic). Quarantine is applied on a modem experiencing errors for few
continuous seconds. Modem is restored to normal operation automatically after one
minute free of errors.
7. In the Description field, you may either manually enter a detailed description or
information (up to 1300 characters) on the HSL, or you may import a *.txt file by
clicking the From File button.
NOTE: this description also appears in the HSL Topology view.
8. To Restore HSL default configuration from the Template, click the Restore HSL
Template button. The HSL template is saved locally on the computer, and can be
imported or Exported from/to Another PC.
To enter the current configuration into the configuration template checkmark the Save
configuration to HSL template button.
NOTE: The HSL Configuration file also stores the HSL calibration parameters. Usage of
this file is also accessed through the HSL calibration pane.
9. Click OK.
