Enhanced Data Rate Tests Running a Script in Standard Mode
7-34 PN: 13000-00205 Rev. N MT8852B Operation Manual
The Diff phase results page displays.
Packets received: The number of packets transmitted by the EUT and successfully
received by the MT8852B
Packets in error: The number of packets received that had errors in the PRBS9
payload as detected by the MT8852B.
Percent: Ratio of packets received to packets in error.
3. Press the [Extended] soft key to display more detailed test results. An example of the
first extended page is shown below.
4. Page through the extended screens with the soft key in the normal manner, or press the
[Summary] soft key to revert to the initial summary page.
Figure 7-47. EDR Differential Phase Results
Figure 7-48. EDR Differential Phase Extended Results
Note
In the Bluetooth specification, this test is performed only on 2-DH1 and 3-DH1
packets on channel 0.
