Testing in Null Packet Mode Running a Script in Null Packet Mode
9-2 PN: 13000-00205 Rev. N MT8852B Operation Manual
Output Power Test
The MT8852B transmits a Poll packet to the EUT. The EUT responds by sending a Null
packet to the MT8852B at its maximum output power. The received power of the Null packet
is measured by the MT8852B.
The table below details the test conditions and the associated default settings. Permitted
variations from the default setting are detailed in the “User Range” column.
Results
1. Position the cursor at "Output power" in the Script menu.
2. Press the [Results] soft key.
The Output power results page displays.
Figure 9-1. Output Power Test
Table 9-2. Output Power Test Conditions
Parameter Default value User Range
Hopping test mode Defined Defined, All, Any
Number of packets 10 1 to 10,000
Figure 9-2. Output Power Results
