Low Energy Tests Running a Script in Standard Mode
7-54 PN: 13000-00205 Rev. N MT8852B Operation Manual
Maximum Input Power Test
After sending a test control, the MT8852B sends BLE reference packets to the EUT at
-10 dBm. The number of packets received at the EUT is counted and this data is then read by
the MT8852B over the HCI or 2-Wire connection. This test is not required for BLR packets.
The table below details the test conditions and the associated default settings. Permitted
variations from the default setting are detailed in the “User Range” column.
Results
1. Position the cursor at "Max input power" in the Script menu.
2. Press the [Results] soft key.
The Maximum input power results page displays.
Figure 7-74. Low Energy Maximum Input Power Test
Table 7-23. Maximum Input Power Test Conditions
Parameter Default value User Range
Number of packets 1500 (444000 bits) 1 to 10,000
Test tx power -10.0 dBm -90.0 dBm to 0.0 dBm
Packet type BLE BLE, 2LE
Figure 7-75. Low Energy Max Input Power Results
