General Information Product Description
MT8852B Operation Manual PN: 13000-00205 Rev. N 1-3
1-2 Product Description
The MT8852B is a complete Bluetooth test solution that supports Basic Rate, Enhanced Data
Rate (EDR), and low energy measurements in compliance with the latest Bluetooth
specification. The MT8852B is the ideal instrument for design proving and production test of
Bluetooth enabled products.
Model Types
The table below lists the functionality of each MT8852B model type and explains how the
model can be identified by referring to the options sticker on the rear panel (refer to figure 4-8
for details).
Figure 1-1. MT8852B Bluetooth Test Set
Table 1-3. MT8852B Model Types
Audio Testing EDR Testing Rear Panel Notation
MT8852B Supported Supported Option 19, 25
MT8852B-040 Not supported Not supported No rear panel notation
MT8852B-041 Supported Not supported Option 19
MT8852B-042 Not supported Supported Option 25
MT8852B-043 Limited functionality model compatible with
Bluetooth low energy measurements only. Basic
Rate, audio, and EDR tests are not supported.
Option 29
Note
Options are also available to retrofit audio, EDR, and low energy functionality at a
later date if testing requirements change. Refer to table 1-4 for details of available
options.
