MT8852B Specification
A-2 PN: 13000-00205 Rev. N MT8852B Operation Manual
Accuracy +20 dBm to –35 dBm, ±1 dB
+22 dBm to +20 dBm, ±1.5 dB
Enhanced Power
Control
TRM/CA/BV-14-C
Measurement
configuration
Hopping: OFF
Loopback or TX mode
Payload: PRBS9
Packet type: DH1, 2DH1, 3DH1
Displayed result Maximum power for each packet type
Minimum power for each packet type
Maximum power step for each packet type
Minimum power step for each packet type
Maximum power difference at any step between DHn and 2DHn or
3DHn packets
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Measurement range +22 dBm to -35 dBm average power (+23 dBm peak power)
Resolution 0.1 dB
Accuracy +20 dBm to -35 dBm, ±1.0 dB
+22 dBm to +20 dBm, ±1.5 dB
Initial Carrier
Frequency Tolerance
TRM/CA/BV-08-C
Measurement
configuration
Hopping: OFF or ON – measure at Defined, All, or Any frequencies
Loopback or TX mode
Payload: PRBS 9
Packet type: DH1
Displayed results Average initial frequency error
Maximum positive frequency error
Maximum negative frequency error
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
RF input measurement
range
+20 dBm to -35 dBm
Initial frequency error
measurement range
0 Hz to ±150 kHz
Frequency resolution 1 kHz
Accuracy 500 Hz ± Frequency Standard
Carrier Frequency Drift TRM/CA/BV-09-C
