MT8852B Specification
MT8852B Operation Manual PN: 13000-00205 Rev. N A-3
Measurement
configuration
Hopping: OFF or ON – measure at Defined, All, or Any frequencies
Loopback or TX mode
Payload: 10101010
Packet type: DH1, DH3, DH5
Displayed results Carrier frequency drift
Drift rate
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
RF input measurement
range
+20 dBm to –35 dBm
Frequency drift
measurement range
0 Hz to 200 kHz, and >2000/50 µs
Frequency resolution 1 kHz
Characteristic/Parameter Specification
Sensitivity - Single Slot
Packets
RCV/CA/BV-01-C
Measurement
configuration
Hopping: OFF or ON, user selectable
Loopback only
Payload: PRBS9
Packet type: DH1
Dirty transmitter (as defined in the RF test spec): ON or OFF, user
defined
Displayed results BER (percentage)
Total number of bit errors and FER
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Number of measured bits 1 to 10,000 packets (216 to 2,160,000 bits)
Output power range 0 dBm to –90 dBm, resolution 0.1 dB
Output power accuracy ±1 dB, 0 dBm to –80 dBm
BER/FER measurement
range
0.000% to 100%
BER/FER resolution 0.001%
Sensitivity - Multi Slot
Packets
RCV/CA/BV-02-C
