Anritsu MT8852B - Rear Panel Layout

Rear Panel Layout Instrument Overview
4-8 PN: 13000-00205 Rev. N MT8852B Operation Manual
4-2 Rear Panel Layout
Note
Data Length Extension (DLE) measurements on Bluetooth low energy devices are
available with option 34. 2LE (2 Mbps) measurements are available with option 35
and BLR (long range - LE Coded) measurements are available with option 36.
MT8852B Options 34, 35 and 36 are available for MT8852B units with Option 27
and MT8852B-043 (Low Energy only) units.
Figure 4-8. MT8852B Rear Panel
