Error Messages
D-2 PN: 13000-00205 Rev. N MT8852B Operation Manual
Core busy, try again When driving the MT8852B via GPIB using the auxiliary
command, additional rules have to be applied as listed below.
A. After a CONNECT command, check the connection
complete bit (CON) of the INS register or the ERRLST output
for the connection failure, before sending another command.
B. After the INQUIRY command, check that the inquiry is
complete using status bit (INQ) of the INS register before
sending any other commands except INQCANCEL
command.
DSP not communicating Measurement processor is no longer communicating with the
main processor.
EDR 8PSK Modulation not found The tester was expecting an 8-DPSK modulated EDR packet
but the decoded packet type field does not indicate an
8-DPSK packet.
EDR Expected length mismatch The tester was expecting a payload length of a given number
of bytes, but the decoded payload field does not give the
same result.
EDR Insufficient blocks Insufficient data blocks detected in the EDR portion for
packet analysis to occur.
EDR PI/4 Modulation not found The tester was expecting a /4-DQPSK modulated EDR
packet but the decoded packet type field does not indicate a
/4-DQPSK packet.
EDR Unknown packet type Could not decode packet type.
EDR mod. mode not specified Modulation mode not specified.
EDR option not installed Displays when an EDR test RUN is requested or when trying
to select EDR tests on a non EDR option enabled unit.
EDR sync word exceeds limits The EDR synchronization word has been detected outside of
its expected location.
EUT RS232 not available The MT8852B was requested to update the EUT settings via
the EUT control RS232 interface when the Bluetooth address
source was not set to RS232.
EUT Unsupported feature The EUT does not support the feature that the MT8852B is
attempting to use.
EUT does not support BLE A BLE test RUN was attempted on a device that does not
support BLE.
EUT not reached Max Power The EUT was requested to go to maximum Tx power and a
MAX power LMP has not been received.
EUT not reached Min Power The EUT was requested to go to minimum Tx power and a
MIN power LMP has not been received.
Table D-1. Error Messages
Message Meaning
