Testing in Null Packet Mode Running a Script in Null Packet Mode
9-4 PN: 13000-00205 Rev. N MT8852B Operation Manual
Power Control Test
A power measurement cycle sets the EUT output power to its maximum, steps it down to the
minimum, and then back to the maximum, one step at a time. For each power step a number
of Poll packets are sent to the EUT which responds by sending Null packets back to the
MT8852B.
The table below details the test conditions and the associated default settings. Permitted
variations from the default setting are detailed in the “User Range” column.
Results
1. Position the Cursor at "Power control" in the Script menu.
2. Press the [Results] soft key.
Figure 9-4. Power Control Test
Table 9-3. Power Control Test Conditions
Parameter Default value User Range
Cycles 1
Packets per step 1 1 to 10,000
Minimum test power -35 dBm -40 dBm to 0,0 dBm
Measurement delay 0.1 s 0.1 s to 100 s
