MT8852B Operation Manual PN: 13000-00205 Rev. N A-1
Appendix A — Specifications
A-1 MT8852B Specification
Characteristic/
Parameter
Specification
Basic Rate
measurements
All measurements made in compliance with Bluetooth core
specifications 3.0 + HS Test Suite Structure (TSS) and Test
Purposes (TP) Specification 1.2/2.0/2.0 + EDR/2.1/2.1 +
EDR/3.0/3.0 + HS.
Output Power TRM/CA/BV-01-C
Measurement
configuration
Hopping: OFF or ON – measure at Defined, All, or Any frequencies
Loopback or TX mode
Payload: PRBS 9
Packet type: DH1, DH3, DH5
Displayed results Average power
Peak power
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Measurement range +22 dBm to –50 dBm average power (+23 dBm peak power)
Resolution 0.1 dB
Accuracy +20 dBm to –35 dBm, ±1 dB
+22 dBm to +20 dBm, ±1.5 dB
Power Control TRM/CA/BV-03-C
Measurement
configuration
Hopping: OFF
Loopback or TX mode
Payload: PRBS 9
Packet type: DH1, DH3, DH5
Displayed results Maximum power
Minimum power
Maximum step size
Minimum step size
Power at each power step
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Measurement range +22 dBm to –35 dBm average power (+23 dBm peak power)
Resolution 0.1 dB
