Running a Script in Single Payload Mode Test Conditions
MT8852B Operation Manual PN: 13000-00205 Rev. N 8-3
8-4 Test Conditions
The RF measurements that can be performed are dependent on the packet type that has been
configured in single payload mode. For example, a carrier drift measurement can be
performed only if a 10101010 has been selected. This information is presented in the table
below. A shaded cell indicates that the test can be run at any setting.
8-5 Results
The results are a subset of those detailed in chapter 7.
All results are fully compliant with the RF test specification.
Table 8-2. Tests Supported in Single Payload Mode
Test control Payload Packet type Hopping Dirty mode
Output Power
Off
Init carrier
Off
Carrier drift
10101010 Off
Single sensitivity Loopback PRBS9 DH1
Multi sensitivity Loopback PRBS9 DH3 or DH5
Modulation index 101010101
or 11110000
Off Off
