MT8852B Operation Manual PN: 13000-00205 Rev. N 8-1
Chapter 8 — Running a Script in
Single Payload Mode
8-1 Single Payload Mode (Not available on MT8852B-043)
Single payload mode uses only a restricted form of test mode signalling. This mode is ideal
for use with EUTs that do not support full test mode signalling and which may experience
problems if standard mode were used.
The MT8852B sends a single test control to put the EUT into the user-defined state and no
further test controls are used.
When single payload mode is selected, a message to this effect displays on the uppermost line
of every page.
8-2 Supported Tests
The table below lists the tests that are supported in single payload mode for each of the
Bluetooth test types.
Table 8-1. Tests Supported in Single Payload Mode
Basic Rate Tests Enhanced Data Rate Tests Low Energy Tests
Output Power
EDR tests are not supported in
single payload mode
Low energy test are not
supported in single payload
mode
Init carrier
Carrier drift
Single sensitivity
Multi sensitivity
Modulation index
