Basic Rate Tests Running a Script in Standard Mode
7-18 PN: 13000-00205 Rev. N MT8852B Operation Manual
Multi Slot Sensitivity Test
The MT8852B transmits the longest supported packet type with a PRBS9 payload to the EUT
at a defined power level (-70 dBm by default). If the dirty parameters are enabled then every
20 ms the MT8852B changes the transmitter parameters as specified in the dirty transmitter
table for this test. The EUT loops back the received data and a bit error rate (BER)
calculation and frame error rate (FER) calculation is performed by the MT8852B test set.
The test is repeated with hopping off for each of the frequencies selected (LOW, MEDIUM
and HIGH) and then with hopping on.
The table below details the test conditions and the associated default settings. Permitted
variations from the default setting are detailed in the “User Range” column.
Results
1. Position the cursor at "Multi sensitivity" in the Script menu.
2. Press the [Results] soft key.
Figure 7-24. Multi Slot Sensitivity Test
Table 7-8. Multi Sensitivity Test Conditions
Parameter Default value User Range
Number of packets 590 (127400 bits) 1 to 10,000
Test Tx power -70.0 dBm -90 dBm to 0.0 dBm
Payload pkt count Transmitted Transmitted, Received
Packet type Longest Longest, DH3, DH5
Hopping OFF&ON ON, OFF&ON, OFF
Dirty transmitter OFF OFF, ON
