Running a Script in Standard Mode Basic Rate Tests
MT8852B Operation Manual PN: 13000-00205 Rev. N 7-15
Single Sensitivity Test
The MT8852B transmits DH1 packets with a pseudo random payload (PRBS9) to the EUT at
a defined power level (-70 dBm by default). If the dirty transmitter parameters are applied,
then every 20 ms the MT8852B changes the transmitter parameters as specified in the dirty
transmitter table for this test. The EUT loops back the received data to the MT8852B at its
maximum power where bit error rate (BER) and frame error rate (FER) calculations are
performed. The test is repeated with hopping off for each of the frequencies selected (LOW,
MEDIUM and HIGH) and then with hopping on.
The table below details the test conditions and the associated default settings. Permitted
variations from the default setting are detailed in the “User Range” column.
Results
1. Position the cursor at "Single sensitivity" in the Script menu.
2. Press the [Results] soft key.
Figure 7-19. Single Sensitivity Test
Table 7-7. Single Sensitivity Test Conditions
Parameter Default value User Range
Number of packets 7408 1 to 10,000
Test Tx power -70.0 dBm -90 dBm to 0.0 dBm
Payload pkt count Transmitted Transmitted, Received
Hopping OFF&ON ON, OFF&ON, OFF
Dirty transmitter OFF OFF, ON
