Instrument Overview Front Panel Layout
MT8852B Operation Manual PN: 13000-00205 Rev. N 4-7
Test Group Availability
The test groups enabled for use on each MT8852B are determined by the model type and the
options installed. The model type and option combinations are summarized in the table
below.
Component Tests
The Bluetooth tests available within each test group on the MT8852B are listed in the table
below.
Table 4-2. Model Types and Test Groups
Basic Rate EDR Low Energy
MT8852B
Available Available Not available
MT8852B + option 27
Available Available Available
MT8852B-040
Available Not available Not available
MT8852B-040 + option 27
Available Not available Available
MT8852B-041
Available Not available Not available
MT8852B-041 + option 27
Available Not available Available
MT8852B-042
Available Available Not available
MT8852B-042 + option 27
Available Available Available
MT8852B-043 Not available Not available
Available
Table 4-3. Tests Supported in Standard Mode
Basic Rate Tests Enhanced Data Rate Tests Low Energy Tests
Output power Relative Tx power Output power
Power control Carrier & mod Carrier & drift
Enhanced power control Differential phase Modulation index
Initial carrier EDR sensitivity Sensitivity
Carrier drift EDR BER floor PER integrity
Single sensitivity EDR max input level Max input power
Multi sensitivity
Modulation index
Max input power
