MT8852B Specification
A-4 PN: 13000-00205 Rev. N MT8852B Operation Manual
Measurement
configuration
Hopping: OFF or ON, user selectable
Loopback only
Payload: PRBS 9
Packet type: DH3, DH5
Dirty transmitter (as defined in RF test spec): ON or OFF, user
defined
Displayed results BER (percentage)
Total number of bit errors and FER
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Number of measured bits 1 to 10,000 packets (for DH3, 1,464 to 14,640,000 bits),
(for DH5, 2,712 to 27,120,000 bits)
Output power range 0 dBm to –90 dBm, 0.1 dB resolution
Output power accuracy ±1 dB, 0 dBm to –80 dBm
BER/FER measurement
range
0.000% to 100%
BER/FER resolution 0.001%
Modulation Index TRM/CA/BV-07-C
Measurement
configuration
Hopping: OFF
Loopback or TX mode
Payload: 11110000 and 10101010
Packet type: DH1, DH3, DH5
Displayed results Frequency deviation
f1max
f2max
f1avg
f2avg and f2avg/f1avg plus % of f2max <115 kHz
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
RF input measurement
range
+20 dBm to –35 dBm
Deviation measurement
range
0 Hz to 350 kHz peak
Deviation resolution 1 kHz
Accuracy 1% for modulation index = 0.32
Maximum Input Power RCV/CA/BV-06-C
