MT8852B Specification
MT8852B Operation Manual PN: 13000-00205 Rev. N A-5
Measurement
configuration
Hopping: OFF
Loopback only
Payload: PRBS 9
Packet type: DH1
Displayed results BER (percentage)
Total number of bit errors and FER
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Number of measured bits 1 to 10,000 packets (216 – 2,160,000 bits)
Output power range 0 dBm to –90 dBm, resolution 0.1 dB
Output power accuracy ±1 dB, 0 dBm to –80 dBm
EDR Measurements
EDR Relative Transmit
Power
TRM/CA/BV-10-C
Measurement
configuration
Hopping: Off and On – measure at Defined, All, or Any frequencies
Modulations: /4DQPSK and 8DPSK
Packet type: 2-DH1, 3, 5 and 3-DH1, 3, 5
Loopback or Tx mode
EUT power level: Max and Min
Displayed results Max differential power (from all packets)
Min differential power (from all packets)
Average differential power (over all packets)
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Measurement range +20 to –35 dBm average power, (+23 dBm peak power)
Relative power resolution 0.01db, GFSK to /4DQPSK and 8DPSK
Relative power accuracy Relative power measurement accuracy between GFSK and
/4DQPSK or 8DPSK, 0.2 dB typical for a power difference of <6 dB
Relative power
measurement range
Relative power measurement range between GFSK and /4DQPSK
or 8DPSK, (PGFSK–8 dB) < PDPSK < (PGFSK +4 dB)
EDR Carrier Frequency
Stability
and Modulation
Accuracy
TRM/CA/BV-11-C
