Instrument Overview Front Panel Layout
MT8852B Operation Manual PN: 13000-00205 Rev. N 4-3
4. Press the [Enter] soft key.
Numeric/Alphabetic Entry
Follow the procedure below if the selected setting supports alphabetic entry.
1. Use the or keys to position the cursor at the required item.
2. Press to clear the current setting and enable data entry.
3. Enter a new setting from the keypad.
The entry on screen reflects the number of times that the key is pressed. A single key
press results in entry of the number appearing beneath the key. Pressing the key twice
in succession results in entry of the first of the letters appearing beneath the key.
Further successive key presses result in the entry of the second, third, or forth letter.
The [Forward] soft key can be used if consecutive entry of two or more identical letters
or numbers is required from the same key. Make the first entry in the manner
described above and then press [Forward] to move the cursor forward and enable entry
again.
4. Press the [Enter] soft key.
The table below shows the key presses required to enter the address 000091E082A5.
Note If a mistake is made, press to delete the last value entered.
Table 4-1.
Required Entry Entry Method
0 Press the 0 key followed by the [Forward] soft key.
0 Press the 0 key followed by the [Forward] soft key.
0 Press the 0 key followed by the [Forward] soft key.
0 Press the 0 key.
9 Press the 9 key.
1 Press the 1 key.
E Press the 9 key three times in succession.
0 Press the 0 key.
8 Press the 8 key.
2 Press the 2 key.
A Press the 8 key twice in succession.
5 Press the 5 key.
