Electrical data
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
70
of 346
3.4
Footnotes refer to Zpage 76–.
BM5331 BM5331-A BM5332 BM5332-A BM5333 BM5333-A
Input rated power
1) 9)
13.4 kW 22.4 kW 33.6 kW
Input rated current
1) 9)
21 A 35 A 53 A
DC link voltage (U
DC
)
1)
60 V - 760 V
DC link capacitance (internal) 330 µF 660 µF 1175 µF
DC link discharge time
(internal DC link capacitance)
240s 480s 900s
Output voltage
(U
AC
)
1) 3)
0 - 500 V
Output frequency at 4 kHz
4)
0 - 450 Hz
Output rated current
(I
AC
RMS)
1) 2) 5)11)
at
4kHz
4)
2x12A 2x20A 2x30A
2 x 28 A with UL
Output rated current
(I
AC
RMS)
1) 2) 5)11)
at
8kHz
4)
2x8.4A 2x14A 2x21A
Output rated current
(I
AC
RMS)
1) 2) 5)11)
at
16 kHz
4)
2x4.8A 2x8A 2x12A
Output peak current
(I
AC
RMS)
1) 5) 6)11)
at
4kHz
4)
2x24A 2x40A 2x60A
Output peak current
(I
AC
RMS)
1) 5) 6)11)
at
8kHz
4)
2x16.8A 2x28A 2x42A
Output peak current
(I
AC
RMS)
1) 5) 6)11)
at
16 kHz
4)
2x9.6A 2x16A 2x24A
Short-time operation KB 200 %
Max. length of time peak current
6)
Refer to ZLoad cycle according EN61800-6– as from page 78
Power loss with regard to power supply Max. 210 W Max. 310 W Max. 460 W
Power loss with regard to control voltage
supply (air-cooled)
7)
Max. 42 W Max. 55 W
Power loss with regard to control voltage
supply (cold plate cooling)
7)
Max.
39 W
-Max.
39 W
-Max.
39 W
-
Current of the integrated
brake control
(option)
8)
Max. 2 x 2,0 A
Cooling air requirement power heat sink 55 m
3
/h - 55 m
3
/h - 100 m
3
/h -
Cooling air velocity power heat sink - > 5 m/s - > 5 m/s - > 5 m/s
Cooling air requirement internal space of
device
10 m
3
/h - 10 m
3
/h - 10 m
3
/h -
