3.5
108.10 Bit pattern status bit 14
This parameter is only relevant for axis units.
Mask for the freely definable Status Bit 14 in the drive manager Status Word Z108.3–.
If at least one bit from the mask is set in the selected parameter Z108.9–, Bit 14 in the
Status Word will be set.
108.11 Parameter selection status bit 15
This parameter is only relevant for axis units.
Selection of the parameter for the freely definable Status Bit 15 in the drive manager Sta-
tus Word Z108.3–.
If at least one bit from the mask 108.12 is set in the selected parameter, Bit 15 in the Sta-
tus Word will be set.
When StatusB15_IdSelect = 0, the mapping for Bit 15 is switched off.
108.12 Bit pattern status bit 15
This parameter is only relevant for axis units.
Mask for the freely definable Status Bit 15 in the drive manager Status Word Z108.3–.
If at least one bit from the mask is set in the selected parameter 108.11, Bit 15 in the Sta-
tus Word will be set.
108.13 QUICK STOP reaction code
This parameter is only relevant for axis units. 
Value Meaning
0 Inhibit drive immediately
1 Return to ramp-down ramp
2 Return to Quick Stop ramp
3 Return to current limit
4 Return to voltage limit (acts like current limit)
5 Return to ramp-down ramp and remain in Quick Stop active mode (renewed
enabling possible)
6 Return to Quick Stop ramp and remain in Quick Stop active mode (renewed
enabling possible)
