Description of the Software Modules and Parameters
Parameter manual b maXX BM5800
Document No.: 5.16029.03
689
of 814
3
101.6 Channel 3 source parameter Id
See Z101.3–
101.7 Channel 4 source parameter Id
See Z101.3–
101.8 Channel 5 source parameter Id
See Z101.3–
101.9 Channel 6 source parameter Id
See Z101.3–
101.10 Channel 7 source parameter Id
See Z101.3–
101.11 Trigger source parameter Id
Parameter ID for trigger events that are freely programmable:
The value of RSP Trigger Source Pxxx (axis indicated through trigger axis mask, refer to
Z101.13–) is compared with the trigger comparison value (Z101.15–) and a trigger is ac-
tivated when the trigger condition (Z101.14–) is met.
101.12 Trigger mode
Setting the corresponding bit will trigger the ring buffer for the associated event.
NOTE!
Trigger data changes must always be made in Status 0 (Recording Stop) only.
