3.10
101.13 Trigger axis mask
Axis mask for Trigger Source Pxxx.
101.14 Trigger condition
Trigger condition
101.15 Trigger compare value
The value of RSP Trigger Source Pxxx (axis indicated through trigger axis mask is com-
pared with the trigger compare value (101.15) and a trigger is activated when the trigger
condition (101.14) is met.
Bit # Value Trigger event
0 0x0001 Reserved
1 0x0002 Reserved
2 0x0004 Freely programmable trigger event
3 0x0008 Reserved
4 0x0010 Trigger on positive edge
5 0x0020 Trigger on negative edge
15 ... 6 Reserved
Bit # Trigger event
0 Axis 0
1 Axis 1
15 ... 2 Reserved
Value Trigger condition
0 No condition
1 Value greater than comparison value
2 Value equal to comparison value
3 Reserved
4 Value less than comparison value
