104.3 Signal input 1 source Pxxx
The parameter number for the signal source of Channel 1 can be entered here. Entries
are only possible with the FFT command Stop.
104.4 Signal input 2 source Pxxx
The parameter number for the signal source of Channel 2 can be entered here. Entries
are only possible with the FFT command Stop.
104.5 Signal input 1 / 2 axis
The axis number for the two input signals and the output signal can be configured here.
The output signal is thereby always assigned together with the input signal Signal_1. En
-
tries are only possible with the FFT command Stop.
Definition:
104.6 Signal out target-Pxxx
The parameter for a target parameter can be entered here. The output signal from the
signal generator is thereby routed through the system as an excitation signal. Entries are
only possible with the FFT command Stop.
28 Check Average
40 FFT result is available for readout
41 Finish
Status Meaning
Value Meaning
0x00 Both inputs and output to axis 1;
This is the default setting.
0x01 Reserved
0x10 Reserved
0x11 Both inputs and output to axis 2 (only for double axis units)
