Error descriptions
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
734
of 814
4.5
169 Application error for testing the error
responses
Application error for testing the error responses.
The error can be triggered uniquely as follows:
1) Write the value 5 to P100.1 Info manager error command
2) Write the error number 169 to P100.6 Info manager launch
error
The error can be used to test the different error responses, e.g. pull-
back, without triggering a „true“ error.
170 Firmware for communication processor
could not be downloaded
Firmware for communication processor could not be downloaded
The error is messaged, if the firmware could not be downloaded to
the communication processor at the boot sequence.
Either both firmware files (actual and fallback) of the communication
firmware are faulty or nonexistent (error info1 = 0) or an error has
occurred at the file download to the communication processor (error
info1 = 1).
Pulse block
171 Wrong power amplifier serial number
172 Lead drive error Error within communication between two drives. The coupled drive
reported an error. The receiver drive reports error 172, if a new error
reaction is invoked and the error reaction is none of "no reaction" nor
"no error, no reaction". Then the drive reacts with the received error
reaction. The entry in the error reaction table is not used, since the
received error reaction will be used.
No response
173 PLC Translation error Error when translating the PLC project No response
174 PLC runtime error PLC runtime error No response
175 Application error 1 Freely definable application error 1 No response
176 Application error 2 Freely definable application error 2 No response
177 Application error 3 Freely definable application error 3 No response
178 Application error 4 Freely definable application error 4 No response
179 Application error 5 Freely definable application error 5 No response
180 Value cannot be changed due to
dependency on another parameter
value
201 Exceeded limit pos. speed error value Speed error value > Maximum positive speed difference (parameter
Z6.7–)
No response
202 Exceeded limit neg. speed error value Speed error value < Maximum negative speed difference (parameter
Z6.8–)
No response
203 Positive overspeed limit exceeded x2 speed actual value > Positive overspeed limit (parameter Z6.5–) Pulse block
204 Negative overspeed limit exceeded x2 speed actual value < Neg. overspeed limit (parameter Z6.6–) Pulse block
205 Motor i2t overload The current i2t value (Z6.28–) has exceeded the limit value for the
i2t model (Z6.29–).
Pulse block
206 LT monitoring approached; max. torque
current was limited
I*t monitoring of power unit is operating; the maximum available
torque current is limited.
Details see ZOverload monitoring of the power unit– on page 709.
No response
207 Exceeded position error limit 1 Error occurs when position error limit 1 is exceeded. Pulse block
208 Exceeded position error limit 2 The error occurs when position error limit 2 is exceeded Pulse block
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
