Summary of all Parameters
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
768
of 814
5
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write Axis-independent
102.35 Device type code STRING 1:1 X
102.39 Fpga Id CU UDINT 0 0xFFFFFFFF 0 1:1 X X
103.1 FPGA Data DINT 0 0 0 1:1 X X
104.1 Command UDINT 0 4 0 1:1 X X
104.2 Status UDINT 0 41 0 1:1 X X
104.3 Signal input 1 source
Pxxx
UDINT 0 0xFFFFFFFF 0 1:1 X X
104.4 Signal input 2 source
Pxxx
UDINT 0 0xFFFFFFFF 0 1:1 X X
104.5 Signal input 1 / 2 axis UINT 0 0x11 0 1:1 X X
104.6 Signal out target-Pxxx UDINT 0 0xFFFFFFFF 0 ID 1:1 X X
104.7 FFT mode UDINT 0 0xFFFF 0 1:1 X X X
104.8 FFT info DINT 0 12 0 1:1 X
104.9 FFT length DINT 64 4096 4096 1:1 X X
104.10 FFT windowing UINT 0 5 1 1:1 X X
104.11 Average number setup DINT 0 20000 16 1:1 X X
104.12 Signal out amplitude FLOAT -1e+9 1e+9 0 1:1 X X
104.13 Signal output offset FLOAT -1e+9 1e+9 0.000000e+00 1:1 X X
104.14 Frequency for sinus
generator
FLOAT 0 8000 0 Hz 1:1 X X
104.15 Signal out FLOAT -1e+9 1e+9 0 1:1 X X
104.16 Input signal 1 FLOAT -1e+9 1e+9 0.000000e+00 1:1 X X
104.17 Input signal 2 FLOAT -1e+9 1e+9 0.000000e+00 1:1 X X
104.18 Actual average DINT 0 20000 0 1:1 X X
104.19 Max. frequency FLOAT 0.000000e+00 8000 2000 Hz 1:1 X X
104.20 Frequency resolution FLOAT 0.000000e+00 62.5 9.765625e-01 Hz 1:1 X X
104.21 FFT data FLOAT 0 0 0 1:1 X X
104.22 Prbs register length UINT 0 19 19 1:1
104.23 Prbs register clock UINT 1 0xFFFF 1 1:1
105.1 Command DINT 0 10 0 1:1
105.2 Status UDINT 0 0xFFFFFFFF 0 1:1 X
105.3 Message RECOR
D
X
105.4 Record name STRING 1:1 X
105.5 Record Id UDINT 0 0xFFFFFFFF 0 1:1 X
105.6 Dataset index UINT 1 7 1 1:1
105.7 ValidDatasets BIT-
FIELD
1 0x7F 1 1:1 X
105.8 DatasetSource UINT 0 7 0 1:1
105.9 DatasetDest UINT 0 7 0 1:1
105.10 Boot Mode SAF-XXX WORD 0 0xFFFF 1 1:1 X X
