Baumuller b maXX BM5800 - Page 86

Configuration
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
86
of 814
3.4
19.10 Motor nominal torque
current
FLOAT 0.1 10000 3.5 A 1:1 X
19.11 Ke factor in V/Nnom FLOAT 0 1000 0 V/N
nen
n
1:1 X
19.12 Cutt-off frequency PT1-
filter Isq set value
FLOAT 0.0 3000 0.0 Hz 1:1 X
19.17 Isq additive set value FLOAT -10000 10000 0.0 A 1:1 X
19.21 Isq Additive set value 2 FLOAT -10000 10000 0.0 A 1:1 X
19.30 Slip frequency actual
temperature
FLOAT 0.0 100 2,384615 Hz 1:1 X
19.32 Rotor time constant FLOAT 0.0 20 20 s 1:1 X
19.50 Notch position O.K. UINT 0x0 0xF 0x1 1:1 X
19.51 Current ref. for notch
position detection
FLOAT 0.0 100 50 % 1:1 X
19.52 Modus motor operating
mode
UINT 0 2 0 1:1 X
19.61 Delay reference current FLOAT 0 5 0 ms 1:1 X
107.1 Version UINT 0 0xFFFF 0 1:1 X
107.2 Motor type STRING 1:1 X
107.3 Article number UDINT 0 0xFFFFFFFF 0 1:1 X
107.4 Serial number UDINT 0 0xFFFFFFFF 0 1:1 X
107.5 Nominal operation mode UINT 0 0xFFFF 0 1:1 X
107.6 Nominal power FLOAT 0 655.35 5 kW 1:1 X
107.7 Nominal speed UINT 1 65535 3000 U/min 1:1 X
107.8 Nominal voltage FLOAT 0 6553.5 0 V 1:1 X
107.9 Nominal current FLOAT 0 6553.5 3.5 A 1:1 X
107.10 Standstill current FLOAT 0 6553.5 0 A 1:1 X
107.11 Standstill torque FLOAT 0 42949672.95 0 Nm 1:1 X
107.12 Power factor FLOAT 0 1.000 0,9 1:1 X
107.13 Nominal frequency FLOAT 0 6553.5 0 Hz 1:1 X
107.14 Magnetic current FLOAT 0 6553.5 0.01 A 1:1 X
107.15 Slip frequency cold FLOAT 0 655.35 2 Hz 1:1 X
107.16 Slip frequency warm FLOAT 0 655.35 3 Hz 1:1 X
107.17 Slip temperature cold UINT 0 655 0 Grad
C
1:1 X
107.18 Slip temperature warm UINT 0 655 100 Grad
C
1:1 X
107.19 Pole pairs UINT 1 65535 3 1:1 X
107.20 Ke factor FLOAT 0 6553.5 20 V/1000
U/min
1:1 X
107.21 Max current FLOAT 0 6553.5 0 A 1:1 X
107.22 Peak torque FLOAT 0 42949672.95 0 Nm 1:1 X
107.23 Friction moment FLOAT 0 655.35 0 Nm 1:1 X
107.24 Attenuation factor FLOAT 0 655.35 0 Nm/10
00U/mi
n
1:1 X
107.25 Max speed electr. UINT 0 65535 0 U/min 1:1 X
107.26 Max speed mech. UINT 0 65535 0 U/min 1:1 X
107.27 Max temperature UINT 0 250 150 Grad
C
1:1 X
