Uni-Probe LB 490

BERTHOLD TECHNOLOGIES GmbH & Co. KG

6 – 573

Volume 6 3 Device-specific Menus

3.1.14 CONFIGURATION  MEASURE PARAMETER

Configuring the measure parameters.

Three submenus can be selected:

• Damping Data (page 6–573)

• Rad. Interference (page 6–575)

• Pulse Rate Limits (page 6–576).

DAMPING DATA Ta b
