iv | MultiFlo FX Operator's Manual
Strip Washer Optional Accessories 15
Physical Specifications 18
Performance Specifications 21
Peri-Pump Dispenser 21
Syringe Dispensers 22
Strip Washer 23
Space Requirements 25
BioTek's Customer Resource Center 26
Installation 27
Unpack and Inspect the Instrument 28
Install the Waste Tubing 29
Remove the Shipping Hardware 31
Set up the Strip Washer 34
Strip Washer accessories 34
Attach washer module and connect its cable 35
Install the tubing bracket 37
Install the Fluid Supply 38
Install the Waste Bottle 39
Install the muffler 41
Install Washer Manifolds 41
Set Up the Peri-pump Dispenser 44
Attach the Peri-pump Cover Panel 44
Install the Secondary Peri-Pump 46
Install RAD Technology Components 51
Install the Tubing Bracket and RADModule 51
Install the tubing bracket 52
Attach the RADModule to the Tubing Bracket 52
Install RAD Dispense Head 53
Dispense Cassette Diagram 54
Install the Dispense Cassette 56
Install RAD Technology Cassette 58
Prime Trough Inserts 59
Peri-pump Reservoir Holder 60
Shorten the Dispense Cassette Tubing 61
Install the Syringe Dispenser Component 62
Syringe Dispenser Placement Options 63
Install the Syringe Dispenser on Back Shelf 64
Install the Syringe Dispenser on Top 65
Install Tubing and Manifolds for Syringe Dispenser 68
Syringe Dispenser Check Valves 70
Install Inline Filter for 32-Tube Dispensers 71
Install Software/Connect to Computer 71
Connect to Host Computer 72
Connect Power Cable 72
Define Instrument Settings 73
LHC Users Only 73
Enable Waste Sensor 73
MultiFlo™ FX Multi-Mode Dispenser
