Brother HL-S7000DN Service Manual

2-82
Confidential
■ Error code 7402
Paper jam. (While tray 2 paper feed sensor is at paper feeding state, even if a certain amount
of paper is fed, registration front sensor does not change to paper feeding state.)
<User Check>
- Remove the jammed paper.
■ Error code 7501
Paper jam. (When printing is started by tray 3, even if a certain amount of paper is fed, T3
paper feed sensor does not change to paper feeding state.)
<User Check>
- Remove the jammed paper.
Jam A Tray 2
Remove the jammed paper from Tray 2.
Step Cause Remedy
1 Foreign object inclusion in the
front chute
Remove foreign object in the front chute.
2 Foreign object inclusion in the
tray 1
Remove foreign object in the tray 1.
3 Registration front sensor harness
connection failure
Reconnect the registration front sensor
PCB harness.
4 Coming off of paper feed
actuator
Re-assemble the paper feed actuator.
5 Paper feed PCB failure Replace the paper feed PCB ASSY.
6 LT relay PCB failure Replace the LT relay PCB ASSY.
Jam A Tray 3
Remove the jammed paper from Tray 3.
Step Cause Remedy
1 Foreign object inclusion in the
tray 3
Remove foreign object in the tray 3.
2 Coming off of tray 3 paper feed
actuator
Re-assemble the tray 3 paper feed
actuator.
3 T3 paper feed sensor harness
connection failure
Reconnect the T3 paper feed sensor
harness.
4 T3 paper feed motor harness
connection failure
Reconnect the T3 paper feed motor
harness.
5 LT relay PCB failure Replace the LT relay PCB ASSY.

Brother HL-S7000DN Specifications

General

Color	No
Duplex printing	Yes
Maximum duty cycle	275000 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PostScript 3
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	100 ppm
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Sound power level (standby)	40 dB
Sound power level (printing)	64 dB
Total input capacity	500 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	30 W
Power consumption (printing)	130 W
Operating temperature (T-T)	18 - 33 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Black, White
Market positioning	Business
Package weight	52000 g
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	472 mm
Width	478 mm
Height	484 mm
