1.4.12 LAN connection status display (Function code 33)
<Function>
This function allows you to check the status of the wired LAN connection.
<Operating procedure>
(1) Press the 3 button twice in the initial state of the maintenance mode. The wired LAN
connection status described in the table below is displayed on the LCD.
(2) To return the machine to the initial stage of the maintenance mode, press the Cancel
button.
LCD LAN connection status
Active 100B-FD 100B-FD
Active 100B-HD 100B-HD
Active 10B-FD 10B-FD
Active 10B-HD 10B-HD
Inactive Not connected.
