5-38
Confidential
1.4.15
Changing return value of USB No./
Adjusting of left-end print start position on second side in 2-sided printing
(Function code 45)
Changing return value of USB No.
<Function>
When the OS of the computer is Windows Vista
®
, and the computer is connected to a device
through USB 2.0 full speed, the OS might fail to get the serial No. of the USB device
depending on the computer and USB device. When the OS fails to get the serial No., the
return value may continue to increase every time the device is connected to the computer.
To avoid this problem, you can fix the return value of the USB No. to "0" by setting "USBNo. =
ON". (This is the same function as "2.4 Changing Return Value of USB No." in this chapter.)
"*" is displayed at the end of the currently specified function in the LCD display.
<Operating procedure>
(1) Press the 4 and 5 buttons in this order in the initial state of the maintenance mode.
"USBNo." is displayed on the LCD.
(2) Press the OK button. "USBNo.=ON" is displayed on the LCD.
(3) When you press the or button to fix the return value of serial number to "0" or not to
fix it to "0", display "USBNo. = ON" or "USBNo. = OFF", respectively.
(4) Press the OK button. "Accepted" is displayed on the LCD, and the product returns to the
initial state of the maintenance mode.
(5) Turn the power switch of the machine OFF.
Adjusting left-end print start position on second side in 2-sided printing
<Function>
This function is to adjust the left-end print start position on the second side in the left and right
direction if it is displaced in 2-sided printing.
The adjustable range is -100 to 750 (unit: 300 dpi) (The minus direction means the left direction.)
<Operating procedure>
(1) Press the 4 and 5 buttons in this order in the initial state of the maintenance mode.
"USBNo." is displayed on the LCD.
(2) Press the or button to display "DX.XAdjust" on the LCD.
(3) Press the OK button. "DX.XAdjust=**" is displayed on the LCD.
(** represents the currently set value.)
(4) To move the print start position to the left, press the button and decrease the value.
To move the print start position to the right, press the button and increase the value.
(5) Press the OK button. "Accepted" is displayed on the LCD, and the product returns to the
initial state of the maintenance mode.
LCD Description
USBNo. =ON Returns the serial No. of the device. (default)
USBNo. =OFF Returns "0".
Note:
This function is enabled when the power of the machine is turned OFF and ON.
