5-2
Confidential
1.3 List of Maintenance-mode Functions
*The functions shaded in the table above are user-accessible.
Function code Function Refer to:
01 EEPROM parameter initialization 1.4.1(5-3)
09 Printing of test pattern 1.4.2(5-4)
10 Worker switch (WSW) setting 1.4.3(5-5)
12 Operation check of LCD 1.4.4(5-6)
13 Operational check of control panel button 1.4.5(5-7)
17 Purge operations 1.4.6(5-8)
18 Individual operation of each unit 1.4.7(5-10)
19 Adjustment of waste ink box sensor 1.4.8(5-14)
25 Software version check 1.4.9(5-16)
31 Carriage operations 1.4.10(5-18)
32 Operational check of sensors 1.4.11(5-20)
33 LAN connection status display 1.4.12(5-31)
40 EEPROM Dump Print 1.4.13(5-32)
41 USB storage memory formatting function 1.4.14(5-37)
45
Changing return value of USB No./
Adjusting of left-end print start position on second
side in 2-sided printing
1.4.15(5-38)
49 Ink replacement purge inside head 1.4.16(5-39)
67 Continuous print test 1.4.17(5-40)
68 Print adjustment 1.4.18(5-42)
69 Frame pattern print (One-sided) 1.4.19(5-44)
70 Frame pattern print (Two-sided) 1.4.20(5-45)
74 Setting by country 1.4.21(5-46)
77 Printout of maintenance information 1.4.22(5-47)
78 Operational check of fans 1.4.23(5-49)
80 Display of device log information 1.4.24(5-50)
82 Display of device error codes 1.4.25(5-55)
91 EEPROM parameter initialization 1.4.1(5-3)
99 Exit from the maintenance mode 1.4.26(5-55)
Memo:
Although you can select the function code 71, only the blank paper is output.
