1.4.17 Continuous print test (Function code 67)
<Function>
This function allows you to conduct the pick-up and delivery test as printing patterns.
<Operating procedure>
(1) Press the 6 and 7 buttons in this order in the initial state of the maintenance mode.
"SELECT: K 1%" is displayed on the LCD.
(2) Referring to the table below (print pattern), press the or button to select the desired
print pattern.
(3) Press the OK button. "SELECT: A4" is displayed on the LCD.
(4) Referring to the table below (paper size), press the or button to select the desired
paper size.
(5) Press the OK button. "SELECT: TRAY1" is displayed on the LCD.
(6) Referring to the table on the next page (print type), press the or button to select the
desired print type.
(7) Press the OK button. "SELECT: OUTBIN1" is displayed on the LCD.
(8) Referring to the table on the next page (output tray), press the or button to select
the desired Eject stopper tray.
(9) Press the OK button. "PAPER FEED TEST" is displayed on the LCD and the test pattern
starts to be printed under the selected items for paper feed test.
(10) If you press the Cancel button, printing of test pattern is interrupted and the machine
returns to the initial state of the maintenance mode.
<Print pattern>
<Paper size>
* In the case of K1% and K5%, A4 and LETTER sizes only can be selected.
LCD Description
SELECT: K 1% 1% intermittent pattern print (printing of 500 pages)
SELECT: K 5% 5% intermittent pattern print (printing of 500 pages)
SELECT: Lattice Lattice print (Continuous print)
LCD Description
SELECT: A4 A4-size
SELECT: LETTER Letter-size
SELECT: LEGAL Legal-size
SELECT: A5 A5-size
SELECT: B6 B6-size
SELECT: A6 A6-size
To Next Page
