5-59
Confidential
Adjusting of left-end print start position on second side in 2-sided printing
<Function>
This function is to adjust the left-end print start position on the second side in the left and right
direction if it is displaced in 2-sided printing.
The adjustable range is -100 to 750 (unit: 300 dpi) (The minus direction means the left direction.)
<Operating procedure>
(1) While the machine is in the ready state, press the Go and buttons at the same time.
"USBNo." is displayed on the LCD.
(2) Press the or button to display "DX.XAdjust"
(3) Press the OK button. "DX.XAdjust =**" is displayed on the LCD.
(** represents the currently set value.)
(4) To move the print start position to the left, press the button and decrease the value.
To move the print start position to the right, press the button and increase the value.
(5) Press the OK button. "Accepted" is displayed on the LCD, and the machine returns to the
ready state.
2.5 Mode Where Engine Is Not Operating
<Function>
Mode where the machine is started without starting the engine. In this mode, printing is
unavailable, but obtaining the error history and counter information is possible from the LCD
by starting the machine with the main controller alone when the engine is experiencing trouble.
<Operating procedure>
(1) While the power is OFF, press the Go and buttons at the same time to turn ON the
power.
(2) The machine is started without the engine being started.
(3) Check the error history and counter information and turn the power OFF.
Note:
When the machine enters the mode where engine is not operating, 0 is displayed in all
the counters retained by the engine PCB.
To Next Page
