4-38
Confidential
9. WHEN REPLACING PLATEN UNIT
<What to do when replacing the Platen unit>
■ Before replacement
- Nothing in particular
■ After replacement
- 9.1 Input of Platen Adjustment Value (Maintenance Mode: Code 31)
- 9.2 Supply of Ink to Platen Unit and Check of Ink Leak
- 9.3 Resetting of Platen unit Counter
<What you need to prepare>
Nothing in particular
9.1 Input of Platen Adjustment Value
(Maintenance Mode: Code 31)
Refer to Chapter 4, "7.3 Input of Platen Adjustment Value (Maintenance Mode: Code 31)" and
perform it.
9.2 Supply of Ink to Platen Unit and Check of Ink Leak
(1) Check that the ink cartridge is installed.
(2) Press the 1 and 7 buttons in this order in the initial state of the maintenance mode.
"Cartridge" is displayed on the LCD. If the machine displays "No Cartridge" on the LCD,
press the button to display "Cartridge" on the LCD.
(3) Press the Go button. "NORMAL_P ALL" is displayed on the LCD.
(4) Press the Go button. The machine displays "EXECUTING" on the LCD and starts
supplying ink.
(5) Check that no ink is leaking from the junctions between the tubes while ink is being
supplied.
(6) When the machine finishes supplying ink, it displays "COMPLETED" on the LCD.
(7) Press the Go button to return to the initial state of the maintenance mode.
(8) Press the 9 button twice to return to the ready state.
9.3 Resetting of Platen Unit Counter
(1) While the machine is in the ready state, press the Go and buttons at the same time.
"Reset Menu" is displayed on the LCD.
(2) Press the or button to select platen unit, and press the OK button. "1.Reset 2.Exit"
is displayed on the LCD.
(3) Press the 1 button. The machine displays "Accepted" on the LCD. The replacement
counter of the platen unit increases, and the machine returns to the ready state.
(4) Turn OFF the power of the machine.
