Brother HL-S7000DN - Troubleshooting Print Quality Issues

2-110
Confidential
4.2.4 Wrinkles on paper
<User Check>
- Check if the paper is loaded into each paper tray correctly.
- Turn back the paper loaded in each paper tray or change the orientation of the paper by
180°.
- Adjust the paper guide corresponding to the paper size.
- Check if the thickness of the paper is 60 to 105 g/m
2
. (60 to 163 g/m
2
for MP tray)
- Check whether the paper is damp.
4.2.5 Paper inclines diagonally
<User Check>
- Check if the paper is loaded into each paper tray correctly.
- Adjust the paper guide corresponding to the paper size.
- Check if the thickness of the paper is 60 to 105 g/m
2
. (60 to 163 g/m
2
for MP tray)
- Check if too much paper is loaded in the tray.
Step Cause Remedy
1 Paper eject failure Replace the paper eject ASSY.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
