11. WHEN REPLACING PF KIT/AIR FILTER/
HUMIDIFY UNIT/DRIVE SWITCHING UNIT/
WASTE INK BOX
<What to do when replacing the PF Kit/Air filter/Humidify unit/Drive switching
unit/Waste ink box>
- Reset each counter of the periodical replacement parts.
(1) While the machine is in the ready state, press the Go and buttons at the same time.
"Reset Menu" is displayed on the LCD.
(2) Press the or button to select the periodical replacement part you wish to reset, and
press the OK button. "1.Reset 2.Exit" is displayed on the LCD.
The following shows the periodical replacement parts that can be reset.
(3) Press the 1 button. The machine displays "Accepted" on the LCD and returns to the
ready state.
(4) Turn OFF the power of the machine.
- PF Kit MP - Air Filter Case (Air filter)
- PF Kit 1 - Sub tank (Sub tank ASSY)
- PF Kit 2 - CR frame Unit (Carriage unit)
- PF Kit 3 - Platen(Platen frame)
- PF Kit 4 - Ink Supply Unit (Ink refill unit)
- Waste Tank (Waste ink box) - Drive Frame (Drive switching unit)
- Print Head Black (Ink head) - Optimizer Unit (Humidify unit)
- Print Head Pre-C (Pre-coat head)
- Leak Sensor (Waste ink box leak sensor)
