2. PERIODICAL REPLACEMENT PARTS
2.1 Procedures to Replace Periodical Replacement Parts
■ Preparation
Prior to proceeding with the disassembly procedure,
(1) Unplug
-the AC cord,
- the USB cable, if connected, and
- the LAN cable, if connected.
(2) Remove
- the Paper tray
Paper tray
Main body
