4-18
Confidential
2.7 Tightening of Flange nut M3
After all necessary checks and adjustments are finished, completely tighten the Flange nuts
M3 that have been temporarily screwed on the bottom of the Ink head ASSY and Pre-coat
head ASSY.
2.8 Resetting of Each Head Counter
(1) While the machine is in the ready state, press the Go and buttons at the same time.
"Reset Menu" is displayed on the LCD.
(2) Press the or button to select ink head or pre-coat head, and press the OK button.
"1.Reset 2.Exit" is displayed on the LCD.
(3) Press the 1 button. The machine displays "Accepted" on the LCD. The replacement
counter of the ink head or pre-coat head increases, and the machine returns to the ready
state.
(4) Turn OFF the power of the machine.
