Brother HL-S7000DN Service Manual

3-4
Confidential
4. SCREW TORQUE LIST
Note:
For verifying the shape of each screw, refer to “3. SCREW CATALOGUE” in this chapter.
Location of screw Screw type Q' ty
Tightening torque
N
·m (kgf·cm)
ID key holder Taptite cup B M3x8 2 0.5±0.1 (5±1)
Front cover Taptite bind B M4x10 1 0.8±0.1 (8±1)
Rear cover finisher L Taptite bind B M4x10 1 0.8±0.1 (8±1)
Rear cover finisher R Taptite bind B M4x10 1 0.8±0.1 (8±1)
Top cover R Taptite bind B M4x10 1 0.8±0.1 (8±1)
Top cover L Taptite bind B M4x10 2 0.8±0.1 (8±1)
Top cover ASSY Taptite bind B M4x10 6 0.8±0.1 (8±1)
Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)
Earth harness Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Panel rear cover Taptite cup B M3x8 5 0.5±0.1 (5±1)
Earth harness Taptite bind B M3x8 1 0.5±0.1 (5±1)
Panel PCB ASSY Taptite bind B M3x8 1 0.5±0.1 (5±1)
Rear cover L Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Side cover L Taptite cup S M3x6 SR 4 0.8±0.1 (8±1)
Rear cover R Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Side cover R Taptite cup S M3x6 SR 3 0.8±0.1 (8±1)
Under cover B Shoulder screw 2 0.8±0.1 (8±1)
Engine PCB shield plate Taptite cup S M3x6 SR 4 0.4±0.1 (4±1)
Engine PCB ASSY Taptite cup S M3x6 SR 2 0.4±0.1 (4±1)
Refill frame upper Taptite bind B M4x10 7 0.8±0.1 (8±1)
Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)
Refill frame R Taptite cup S M3x6 SR 3 0.8±0.1 (8±1)
Refill frame L Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)
Ink refill Unit Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Taptite bind B M4x10 4 0.8±0.1 (8±1)
Tube holder 2 Taptite cup B M3x8 1 0.5±0.1 (5±1)
Supply pump ASSY Taptite cup S M3x6 SR 4 0.8±0.1 (8±1)
Engine PCB base plate Taptite cup S M3x6 SR 3 0.8±0.1 (8±1)
Sub CR frame rear L Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)

Brother HL-S7000DN Specifications

General

Color	No
Duplex printing	Yes
Maximum duty cycle	275000 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PostScript 3
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	100 ppm
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Sound power level (standby)	40 dB
Sound power level (printing)	64 dB
Total input capacity	500 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	30 W
Power consumption (printing)	130 W
Operating temperature (T-T)	18 - 33 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Black, White
Market positioning	Business
Package weight	52000 g
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	472 mm
Width	478 mm
Height	484 mm
