1.4.24 Display of device log information (Function code 80)
<Function>
This function allows you to display log information on the LCD.
<Operating procedure>
(1) Press the 8and 0 buttons in this order in the initial state of the maintenance mode.
"USB:********" is displayed on the LCD.
(********* represents the serial number of the machine.)
(2) Each time you press the Go or , button, a different item is displayed.
(3) To return the machine to the initial stage of the maintenance mode, press the Cancel
button.
LCD Description
USB:000G8J000166
*1
Serial number
MAC:001BA9 MAC Address
PCB:911309123456 Main PCB serial number
KINK_RM:87% Estimated remaining amount of ink
PINK_RM:67% Estimated remaining amount of pre-coat ink
TTL_PG:00000000 Total of printed pages
KCVRGACC:4.32%
Average coverage rate with the ink cartridges that have been used
KCVRGUSI:4.32% Average coverage rate with the ink cartridge in use
CRT_PG1:00000000 Number of purge operations performed for the ink cartridge in use
CRT_PG2:00000000 Number of purge operations performed for the previously used
ink cartridge
DRYW_PG:00000000 Drying stop page count
MP_PG:00000000 Number of sheets printed from the MP tray
TR1_PG:00000000 Number of sheets printed from the tray 1
TR2_PG:00000000 Number of sheets printed from the tray 2
TR3_PG:00000000 Number of sheets printed from the tray 3
TR4_PG:00000000 Number of sheets printed from the tray 4
DX_PG:00000000 Number of sheets where two-sided are printed
SOTR_PG:00000000 Number of sheets ejected to the standard eject stopper tray
OOTR_PG:00000000 Number of sheets ejected to the optional output tray
A4+LTR:00000000 Total of pages printed on A4 and letter size paper
LG+FOL:00000000 Total of pages printed on legal and folio size paper
B5+EXE:00000000 Total of pages printed on B5 and EXE size paper
ENVLOP:00000000 Number of pages printed on envelopes
A5:00000000 Number of pages printed on A5 paper
OTHER:00000000 Total of pages printed on paper other than the above
PLTNRE:00000000 Total of pages printed on plain, thin, and recycled paper
