5. WHEN REPLACING SUPPLY PUMP ASSY
<What to do when replacing the Supply pump ASSY>
■ Before replacement
- 5.1 Draining Ink from Path Leading to Sub Tank ASSY
■ After replacement
- 5.2 Supply of Ink to Sub Tank ASSY and Check of Ink Leak
- 5.3 Missing Dot Check (Maintenance Mode: Code 68)
- 5.4 Resetting of Supply Pump ASSY Counter
- 5.5 Attachment of Side Cover L
<What you need to prepare>
Nothing in particular
Note:
As you check ink leak after the replacement, check the following without attaching the
side cover L. After the check, attach the side cover L.
