Brother HL-S7000DN Service Manual

5-18
Confidential
1.4.10 Carriage operations (Function code 31)
<Function>
This function allows you to perform the cap operation (cap and uncap), move the carriage to
the position upon shipment, perform the lock operation of the carriage, and adjust the platen
height.
<Operating procedure>
 Cap operations
(1) Press the 3 and 1 buttons in this order in the initial state of the maintenance mode.
"1.CAP PRSR CHK" is displayed on the LCD.
(2) Press the OK button. "Leak Check Start" is displayed on the LCD.
(3) Press the Go button. The cap operation starts.
(4) When the cap operation is finished, the machine returns to the initial state of the maintenance
mode.
 Uncap operations
(1) Press the 3 and 1 buttons in this order in the initial state of the maintenance mode.
"1.CAP PRSR CHK" is displayed on the LCD.
(2)
Press the button or button until "2. UNCAP PRSR CHK" is displayed on the LCD,
and then press the
OK button. "Leak Check Start" is displayed on the LCD.
(3) Press the Go button. The uncap operation starts.
(4) When the unc ap operation is finished, the machine returns to the initial state of the
maintenance mode.
 Moving the carriage to the position upon shipment
(1) Press the 3 and 1 buttons in this order in the initial state of the maintenance mode.
"1.CAP PRSR CHK" is displayed on the LCD.
(2)
Press the button or button until "3.CARIG POS MOV" is displayed on the LCD, and
then press the
OK button. Moving the carriage to the position upon shipment.
(3) When the carriage is back to the position upon shipment, the machine returns to the initial
state of the maintenance mode.
 Carriage lock operations
(1) Press the 3 and 1 buttons in this order in the initial state of the maintenance mode.
"1.CAP PRSR CHK" is displayed on the LCD.
(2)
Press the button or button until "4.CARIG LOCK" is displayed on the LCD, and then
press the
OK button. The carriage lock operation starts.
(3) When the carriage lock operation is finished, the machine returns to the initial state of the
maintenance mode.
 Carriage unlock operations
(1) Press the 3 and 1 buttons in this order in the initial state of the maintenance mode.
"1.CAP PRSR CHK" is displayed on the LCD.
(2)
Press the button or button until "5.CARIG UNLOCK" is displayed on the LCD, and
then press the
OK button. The carriage unlock operation starts.
(3) When the carriage unlock operation is finished, the machine returns to the initial state of the
maintenance mode.

Brother HL-S7000DN Specifications

General

Color	No
Duplex printing	Yes
Maximum duty cycle	275000 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PostScript 3
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	100 ppm
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Sound power level (standby)	40 dB
Sound power level (printing)	64 dB
Total input capacity	500 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	30 W
Power consumption (printing)	130 W
Operating temperature (T-T)	18 - 33 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Black, White
Market positioning	Business
Package weight	52000 g
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	472 mm
Width	478 mm
Height	484 mm
