5-30
Confidential
Optional output tray
Fig. 5-18
Optional tray
Fig. 5-19
Optional output tray eject sensor
Optional output tray
Optional output tray stack sensor
Optional output tray
back cover sensor
solenoid sensor
LT paper size sensor
LT ID switch
LT paper empty sensor/LT plate sensor
LT jam sensor
