3-12
Confidential
2 Engine PCB ASSY
Clamp
Clamp
Clamp
Clamp
Clamp
Clamp
Clamp
Hook
Hook
Engine PCB ASSY
CN18
CN15
CN11CN7
CN10
CN6
CN4
CN3
CN9
CN13 CN22
CN5 CN8
CN24
CN25
CN16
CN23
CN21
CN14
